PSXP Profile System Automatic Sliding Door Package
The Gilgen PSXP profile system sets the benchmark for slimline sliding door packages, combining high-quality components with intelligent Swiss design.
Its modular construction allows for a high level of customisation to any customer’s needs ensuring the right impression is made every time. Although elegantly designed, the profiles are robust and reliable, being tested to 1 million cycles and the vertically interlocking configuration also protects from draughts. With sensors built into the header profile, PSXP retains an attractive appearance suitable for design-conscious environments.
Specification Text
SL-PSXP Profile System Brochures
Door safety & control
- Door system is EN 16361 certified
- Independently tested by TÜV Nord
- Installed and commissioned in compliance with EN 16005 and DIN 18650 safety standards
- Integral safety with GILGEN SL operator
- A range of activation and control modules to choose from customising door opening times, speeds and more
Automatic door configurations
- Self-supporting with pillar reinforcement
- Single-leaf and bi-parting sliding door packages available
- Two and four-leaf telescopic sliding door packages also available
- With side panel, glazed overhead panel and protection leaf
- Door can be within reveal or face fixed
Glazing & surface finish
All our sliding door packages include finishing that enhances aesthetics and makes your electrical sliding door package resistant to corrosion or rust:
- Door features insulated ESG or VSG safety glass (glass thickness 6-24mm)
- Aluminium infills available
- RAL/PCP colours are available or can be provided in an anodised finish
Security / Locking
PSXP profile system includes features to guard against unwanted opening:
- Floor lock / Hook keeps the door in place unless unlocked
- In head lock selectable or can be specified upon request
- Optional multi-point locking – FLUVERI (integrated into door leaf) with manual or automatic settings
Range of applications – PSXP profile system
The PSXP Profile System comes in a selection of variations to suit your business needs
| PSXP sliding door | Clear width | Clear height | max. door leaf weight |
|---|---|---|---|
| Single-leaf | 700 – 2000 mm (redundant 950 – 2000 mm) | up to 3000 mm | 150 kg |
| Bi-parting | 800 – 3000 mm (redundant 900 – 3000 mm) | up to 3000 mm | 2 x 150 kg |
| Two-leaf telescopic | 1100 – 3000 mm (redundant 1100 – 3000 mm) | up to 3000 mm | 2 x 120 kg |
| Four-leaf telescopic | 1200 – 4000 mm (redundant 1200 – 4000 mm) | up to 3000 mm | 4 x 75 kg |
Service & maintenance
As well as providing the highest quality, sliding door packages, we deliver and even install your new doors.
We also offer maintenance packages for your door either annually or bi-annually, and ad hoc assessments can even be carried out at short notice in the event of a fault. If repairs are needed our local experts will be deployed to ensure your door is in full working order as fast as possible.
Purchasing a new sliding door
Ready to purchase your new sliding door? Get in touch by phone (0800 316 6994), email (estimating@gdukds.com) or the online contact form at the bottom of the page.
For more information about the purchase and installation process, access our comprehensive guide on buying your new door.
Check out the rest of our automatic sliding doors.
